With 300 Watts available at 2, 4 or 8 ohms, the MC2301 provides high power to drive even the most difficult loudspeakers. From the demands of massed chorale to full-on rock and roll, the MC2301 delivers the most extraordinarily lifelike and dynamic performance ever heard from a McIntosh tube amplifier.
FEATURES
- 1 Channel x 300 Watts
- Vacuum Tube Design
- Two Balanced Inputs/Outputs
- Multifilar Wound Output Transformers
- Balanced Design
- Unity Coupled Output Circuitry
- Exclusive McIntosh Power Assurance System
- Sentry Monitor
SPECIFICATIONS
ELECTRONIC SPECIFICATIONS
- POWER OUTPUT PER CHANNEL: 300W @ 2, 4 or 8 Ohms
- NUMBER OF CHANNELS: 1
- TOTAL HARMONIC DISTORTION: 0.5%
- S/N BELOW RATED OUTPUT: 117dB
- DYNAMIC HEADROOM: 1.2dB
- DAMPING FACTOR: >15 Wideband
- RATED POWER BAND: 20Hz to 20kHz
- FREQUENCY RESPONSE: +0, -0.5dB from 20Hz to 20,000Hz; +0, -3.0dB from 10Hz to 100,000Hz
CONTROL
- REMOTE POWER CONTROL: Yes
- MULTI-CHANNEL DB25 CABLE: N/A
GENERAL SPECIFICATIONS
- CIRCUIT CONFIGURATION: Quad Balanced, Unity Coupled
- CIRCUIT DESIGN: Vacuum Tube
- MONO BRIDGE: No
- MONO PARALLEL: No
- AUTOFORMER: Transformer
- METERS: Yes
- METER LIGHT SWITCH: Yes
- BALANCED INPUT: Yes
- FRONT PANEL: 1/2" Glass with handles
- ILLUMINATION: LED Fiber Optic
- CHASSIS STYLE: Open Stainless Steel
- GOLD PLATED BINDING POSTS: Yes, 200 amp, 3-way
WEIGHTS & DIMENSIONS
- DIMENSIONS (W X H X D): 17-3/4" (45.09cm) x 12-5/16" (31.27cm) (including feet) x 23" (58.42cm) (including front panel and cables)
- WEIGHT: 116 lbs (52.6 kg)
- SHIPPING WEIGHT: 141 lbs (63.9 kg)
